Visar VSC IPT4VDDLF28 4MP IP Eyeball Camera, 2.8mm, Dual Light (kopeeri) (kopeeri)

VSC IPT4VDDLF28 is a 4 MP weatherproof dome-type network camera, black

Supports H.265+/H.265/H.264+/H.264/MJPEG encoding, two video streams, automatic day/night mode (ICR), 3D DNR, digital WDR, BLC, HLC, ROI encoding, and smart supplemental lighting (Dual Light - IR and white light).

The camera is available with a fixed 2.8 mm lens. IR and white light range is 10–20 m.

Built-in microphone, IP67 protection rating, powered via 12 V DC or PoE. Supports smart motion detection and human VCA events.

Operating temperature: −30 °C to +60 °C.

Technical Specifications:

Image sensor: 1/3" CMOS
Image size: 4 MP (2560 × 1440)
Electronic shutter: 1/3 s ~ 1/100,000 s
Iris type: fixed iris
Min. illumination: 0.09 lux @ F2.2, AGC on; 0 lux with light on
Lens mount: M12
Day/night: ICR
Focus: fixed
WDR: digital WDR
BLC / HLC: yes / yes
Adjustment angles: pan: 0°–360°; tilt: 0°–75°; rotation: 0°–360°
S/N ratio: ≥ 50 dB
Supplemental light range: IR: 10–20 m; white light: 10–20 m

Lens
– 2.8 mm @ F2.2 (H: 96°, V: 53.7°, D: 112°)
DORI distance (2.8 mm): detection 57 m; observation 23 m; recognition 11 m; identification 6 m

DNR: 3D DNR
Image settings: ROI, saturation, brightness, hue, contrast, wide dynamic range, sharpness, mirror, image rotation, noise reduction, etc.; adjustable via client or web browser
ROI (Region of Interest encoding): each ROI area configurable separately

Video
Encoding:
– main stream: H.265+/H.265/H.264+/H.264
– sub stream: H.265+/H.265/H.264+/H.264/MJPEG
H.265 standard: Main Profile @ Level 4.1 High Tier
Resolutions: 4 MP (2560×1440), 3 MP (2304×1296), 1080p (1920×1080), 720p (1280×720), D1, VGA (640×480), 480×240, CIF
Main stream: 4 MP / 3 MP / 1080p / 720p (60 Hz: 1–30 fps; 50 Hz: 1–25 fps)
Sub stream: D1 / VGA / 480×240 / CIF (60 Hz: 1–30 fps; 50 Hz: 1–25 fps)
Bit rate type: VBR / CBR
Bit rate: 64 kbps ~ 3 Mbps
Audio compression: G.711A / G.711U

Interfaces
Network: RJ45
Audio: 1 channel, built-in microphone
Video output: none
Storage: remote network recording
Reset: none

Functions
Remote monitoring: web browser / NVR / NVMS 2.X / mobile app
Simultaneous connections: up to 3 users; multi-stream transmission
Network protocols: UDP, IPv4, IPv6, DHCP, NTP, RTSP, 802.1x, HTTP
Interface protocol: ONVIF
Smart events: (human) line crossing / area intrusion detection
Motion detection: smart motion detection; filters out non-human interference
Security: video, firmware, and settings encryption; illegal login lockout; IP filtering; 802.1x; HTTP basic/digest authentication; watermark; video mask; heartbeat
Browser support: IE11 (plugin required), Chrome 89.0+, Edge 89.0+, Firefox 87.0+, Safari 14.0+

Power and protection
Power: 12 V DC / PoE (IEEE 802.3af)
Power consumption: < 5 W
Protection rating: IP67

Environment
Operating conditions: −30 °C ~ +60 °C; < 95% RH (non-condensing)

Installation and dimensions
Installation: ceiling or wall mount
Dimensions: Ø94.6 × 82.8 mm
Weight: approx. 0.42 kg

Certificates and compliance
Certificates: CE, FCC
Compliance: RoHS; WEEE (2012/19/EU); 94/62/EC; REACH (EC 1907/2006)
